| WHEEL SIZE: | 27.5'', 29'' |
| TRAVEL(MM): | 120mm/100mm/80mm |
| STEERER: | 1-1/8' or 1.5'' Tapered Aluminum |
| AXLE: | 9*100mm( 26''), 9*100mm and 15*100mm (27.5'') |
| SPRING: | AIR, Dual Air, Coil |
| FORK OFFSET: | 44mm |
| UPPER TUBE TYPE | 32mm Aluminum |
| MAX TIRE WIDTH (MM) | 77mm |
| MINIMUM ROTOR SIZE | 180mm |
| E-BIKE APPROVED | E-bike Approved |
| COLOR (FS) | Matte black, Gloss black |
| AXLE TO CROWN: | 27.5'': 495mm 29'': 520mm |
| PITCH: | 140 |
| LOWER: | Magnesium |
